Panel Type	IPS-Type LCD
Display Size	7.0″ / 17.8 cm
Native Resolution	1920 x 1200
Aspect Ratio	16:9
Touchscreen	Yes
Maximum Brightness	2000 nits / cd/m²
Color Support	1.07 Billion Colors (10-Bit)
HDR Support	Yes, HDR10
Color Gamut	100% DCI-P3 100% Rec. 2020
LUT Support	Yes
Image Controls	Anamorphic De-Squeeze, False Color, Focus Peaking, OSD Flip, RGB Parade, Vectorscope, Waveform, Zebra

Video I/O	1x HDMI 2.0 Input 1x BNC (12G-SDI) Input 1x HDMI 2.0 Output 1x BNC (12G-SDI) Output
Embedded Audio	HDMI: 8-Channel SDI: 24-Channel
Audio I/O	1x 1/8″ / 3.5 mm Headphone Output 1x 1/8″ / 3.5 mm Input 1x 1/8″ / 3.5 mm Output
Built-In Speaker	No
Power I/O	1x Barrel Input
Other I/O	1x 2.5 mm (LANC) 1x USB-C (Serial) Input 1x RJ45 (Gigabit Ethernet) Input
Media/Memory Card Slot	Single Slot: SSDmini/SSD with Master Caddy II/III [Supports Recording]
Wi-Fi	Wi-Fi 6E (802.11ax); Dual-Band (2.4 & 5 GHz)
Bluetooth	Yes
Mobile App Compatible	Yes: Android & iOS App Name: AtomRemote Functionality: Adjust Settings, Setup

Video Format	HDMI/SDI (8/10-Bit 4:2:2/4:2:0 YCC) 8K Raw: 30 6K Raw: 60/30 4K Raw: 120 DCI 4K: 60 UHD 4K: 60 DCI 2K: 60 1080p: 120 1080i: 60/50 720p: 60
Gamma Curve	ARRI Log C, ARRI Log C4, Canon Log, Canon Log 2, Canon Log 3, DCI-P3, DCI-P3+, FLAT, FUJIFILM F-Log, FUJIFILM F-Log 2, HDR-HLG, JVC J-Log, Nikon N-Log, OM-Log, Panasonic V-Gamut, Panasonic V-Log, Rec709, Rec2020, RED IPP2, REDlogFilm, S Cinetone, Sony S-Log 2, Sony S-Log 3, V-Log, V-Log L, Wide DR, Z-Log2
Video Signal Conversion	HDMI to SDI SDI to HDMI
Timecode Support	Yes

Input Power	6.2 to 16.8 VDC
Battery	1x L-Series Mount on Fixed Plate

Brand	Atomos
Monitor Type	On Camera Monitor , Recording Monitor

Atomos 7″ Shogun Ultra Monitor-Recorder

Atomos Shogun 7 Ultra Specs
